Making Elevating Construction Surveyors, Part 3 Feat. Brandon Montero

Why Zero Residuals Are Not Good News: Surveying Mastery for Construction Professionals

Zero point zero zero zero. When a trade partner’s data collector flashes that residual after a resection, most people see confirmation that the work is accurate. Brandon Monteiro sees a problem. That perfect number does not mean the work is good. It means there is not enough data to prove the work is bad.

This is one of the most important lessons in the third session of Elevating Construction Surveyors, and it is the kind of insight that separates professionals who produce reliable results from those who produce results that occasionally happen to be correct.

Applied Resection: The Math Behind the Setup

A resection is how a surveyor locates their total station at a convenient vantage point without needing a physical survey nail or rebar beneath the instrument. The instrument shoots angles and distances to at least three known control points, then calculates its own coordinates by triangulating its position from those observations.

This technique is widely used across trades in construction. Electricians use it to locate stub positions for bollards and light poles. HVAC contractors use it to determine overhead penetration locations. Civil layout crews use it to work from inside a busy site where perimeter control points are blocked by structures. The technique is common. The problem, as Brandon puts it, is that it is also very commonly done incorrectly.

Brandon tells the story of a trade partner on a project who was performing a resection using only two control points. Before taking any observations, he had already eyeballed the position of a column corner by taping off chalk lines on the ground, holding his rod at that estimated location, and shooting to it with an eight and a half foot rod held well above his head. The data collector returned exactly zero zero zero on the residual. The contractor was confident. Brandon was not.

Here is why. When you use only two control points for a resection, the instrument has no independent check. If your measurements to both points contain error, the instrument simply accepts both observations and calculates a position that incorporates all of that error without flagging any of it. There is nothing for the residual to compare against. The zero does not mean the work is accurate. It means the system cannot prove it is inaccurate.

When you add a third control point, the instrument now has three observations to reconcile. The residual will not be zero, and that is good. A nonzero residual tells you the magnitude of your error and allows you to evaluate whether it is within acceptable tolerance. Add a fourth or fifth point and you can identify which specific observation is the outlier and remove it, tightening your result further.

The lesson is direct: the more points included in a resection, the more your residuals can reveal. Minimum three points, always. Zero residuals from a two point resection are not a green light. They are a blind spot.

Plan Your Daily Tasks Before You Arrive at the Site

The second concept in this session moves from technical precision to professional discipline: planning the full day before the work begins, not just reviewing the work order.

Brandon draws a distinction that matters. The work order tells you what the task is. A daily plan tells you how the full day is going to unfold, in what order tasks will be performed, what the time constraints are, what resources each stage requires, and where the plan could fall apart if something unexpected happens.

He uses the image of a water hose to make the point. A hose with no nozzle puts water everywhere. The same hose fitted with a narrow nozzle focuses all that force in one precise direction. Showing up to a job site with effort but no plan is the hose with no nozzle. You are expending energy without directing it.

A daily plan includes more than just field tasks. It accounts for reporting back to the office at a specific time, communicating with the team before or after work hours, coordinating with trades who need your results before they can proceed, and protecting time that matters outside of work. Brandon is direct about this: personal time, family commitments, and recovery are also tasks that deserve a slot in the plan, not leftover time after everything else fills in.

The challenge is building the habit. Whether you use a calendar, a spreadsheet, a task management application, or a written list is secondary to the discipline of putting the plan somewhere visible before the day starts. People who plan their days discover where their time actually goes. People who do not plan wonder where it went.

Applied Leveling and Level Loops

The third section covers leveling, one of the most foundational skills in survey and one of the most frequently performed poorly in construction.

Applied leveling means understanding not just how to operate a level but when it is the right instrument for the task, what the math behind the observations looks like, what a properly closed level loop tells you, and how to distribute and mark final adjusted elevations clearly for the people who will use them.

Brandon’s strong recommendation is three wire level loops rather than single wire. Here is the argument. Three wire leveling records top, middle, and bottom wire readings for each observation. This gives you a built in distance check between observations and allows you to see, reading by reading, whether any individual observation is out of range before you close the loop. Single wire leveling gives you less information to work with and fewer opportunities to catch an error in progress.

The common objection is speed. Three wire is slower. Brandon’s response is to get faster at three wire. The same efficiency principles that apply to any field task apply here. Define the workflow, assign roles so no one is waiting on anyone else, and practice until the method becomes fast. Accepting a slower QC method because you have not optimized the better one is the wrong trade.

Level loops close back to the original benchmark. That closure is the quality check. If you surveyed a level loop from a benchmark, set control around a project, and never returned to the benchmark to close the loop, you have no way to know whether error crept into the work. Closing the loop tells you the magnitude of any error and allows you to distribute it through an adjustment rather than having it accumulate at one end of your work.

Jason adds context from his own superintendent and field engineering experience. He has seen elevation problems on multiple projects caused by not using proper leveling techniques. Six inch errors. Eight inch errors. Problems traced back to trigonometric leveling used where a level should have been, or benchmarks that were never independently verified, or level loops that were never closed. In every case, the method was the problem, not the instrument.

Layout Basics: Understanding What the Equipment Is Actually Doing

The final section in this session addresses layout fundamentals, specifically the discipline of performing manual layout operations with a conventional total station rather than relying entirely on robotic operation.

Brandon’s point is subtle but important. When you operate a robotic instrument, the machine turns the angles, finds the prism, and reports a result. You accept the result and move on. The error characteristics of that observation, whether the angle was turned cleanly, whether the observation quality was appropriate for the tolerance required, whether the prism position was actually where the work needed to go: none of that is visible to you. You trust the output.

When you perform the same work conventionally, turning a 90 degree angle manually, flopping the instrument to turn the reverse, and averaging the two to find the true 90, you can see what the instrument is capable of in the physical marks on the ground. You develop calibration for your equipment. You learn when to trust its output and when to apply additional checks.

That calibration is not replaceable by robotic operation. It is built through the experience of working conventionally, making observations, seeing the error, and learning what it means.

If your project needs superintendent coaching, project support, or leadership development, Elevate Construction can help your field teams stabilize, schedule, and flow. The survey principles in this series, from resection to leveling to layout, are part of a larger professional standard that applies to anyone who touches control on a construction project. Learn the math. Verify the work. Plan the day. Trust the process, not just the output.

The Challenge From This Session

Brandon’s challenge for resection is direct: if you understand applied resection, spread that training to the trade partners working around you. The vendors who sell and set up equipment for trades do not have the math background to train them properly. When you see a contractor performing a resection with two points and getting excited about zero residuals, you have an opportunity to help them do better work. Better work from every trade means a better project for everyone on site.

On we go.

Frequently Asked Questions

Why do trade partners use so few control points in a resection if more points produce better results?

Usually because no one has taught them the math behind the method. Vendors prioritize getting people operational quickly, not training them on the statistics behind their observations. The trade partner with two control points is doing what they were shown to do, not what produces reliable results.

When is trigonometric leveling appropriate versus using a level?

A level produces more accurate elevation transfers over short to medium distances. Trigonometric leveling using a total station introduces angle based error that compounds over distance. For project benchmark control and transferring elevations to the site, a level with proper three wire technique and a closed loop is almost always the right choice.

How do you handle a situation where a trade partner’s work does not meet accuracy requirements but they are confident in their results?

Ask to see the number of control points used and the residuals. If the resection used fewer than three points, the zero residual is not a valid quality check. Walk them through what a three point resection would show. In most cases, the trade partner is not being careless. They simply were not trained on why more points matter.

How detailed should a daily survey plan be?

Detailed enough to sequence the tasks in logical order, account for time constraints, identify what each person on the crew will be doing at each stage, and flag the moments where something unexpected could derail the plan. It does not need to be a formal document. It does need to exist before the crew leaves the office.

What is the most common leveling mistake on construction projects?

Not closing the level loop back to the original benchmark. An open loop gives you no independent check on your work. Elevation errors that go undetected at the leveling stage become structural problems later. Close the loop. Every time.
